IK-610LT-RH(B)
Excavation Frame Right Horizontal Milling Head
Plano Milling Head (Gantry Milling Head)
download
Add to Inquiry
Home
Products
PLANO MILLING HEAD
Excavation Frame Right Horizontal Milling Head
1. IK milling heads can upgrade or replacement your existing machine body, milling machine or special machine and also it can bring more stable and high-quality machining benefits for work piece cutting.
2. It is used for mold manufacturing or precision processing.
3. The machine processing for travel is 600 mm. We also provide “No slide” format.
4. This product is used in Gantry (Plano) Milling Machine (vertical / horizontal), suitable for heavy metal cutting, excavation frame and boring.
5. Plano milling head series offer accessory head for you to optional.
It will apply for multi-angle machining to upgrade efficiency and longer machining range.
6. This product of standard is variable frequency motor. Randomly matched with Taiwanese inverter and oil cooler.
7. There are 10 models in IK Plano Milling Machine Head Series.
Model
Unit
IK-610LT-RH(B)
SPINDLE
Spindle Bore Diameter
NT50
Diameter of Spindle Nose
mm
Φ128.6
Spindle Motor
Hp
15(Servo motor)
Step of Spindle Speed
stage
2
Spindle Speed (50Hz)
rpm
L: 0 ~ 1000
H:994 ~ 2000
Spindle Speed (60Hz)
rpm
WORKING RANGE
Max Diameter of Cutter
mm
200
Travel
mm
600(up300 /down300 )
Rapid Travel AC Motor
0.4Kw/0.5Hp AC
3 Phase 4 Poles x 1/40
Rapid Travel Speed
mm/min
177(50Hz)
218(60Hz)
Reversal Slide
2mm/rev
→||← 0.01mm
ACCESSORIES
Oil Cooler for Hydraulic /
Lubrication Oil
P-BO-750P2TSB-192
Variable-frequency Drive
Kw/Hp
15/20
STANDARD ACCESSORIES (● INCLUDE IN PRODUCT)
Spindle Motor
15HP(Servo motor)
Rapid Travel AC Motor
●
Oil Cooler for Hydraulic /
Lubrication Oil
●
Variable-frequency Drive
●
Country of Origin
Taiwan
Weight (Approximate)
kg
638
Warranty
1 year (non artificial mistake)
